Turing Complete

The 1-bit Memory Cell

A close up of the 1-bit Memory Cell. In this image, a 0 is stored, and the enable is off, not allowing new information to be saved.

The Switch Gate

A close up of the Switch Gate. The enable signal is off, not allowing a back signal through to the output.

The AND Gate

A close up of the AND Gate

The NOT Gate

A close up of the NOT Gate.

The NAND Gate

A close up image of the NAND Gate

The Logic Gates

All Logic gates added by v1.0.0 of this mod, in a neat row. From left to right, they are the NAND Gate, NOT Gate, OR Gate, NOR Gate, AND Gate, XOR Gate and XNOR Gate.
